SRNE 60A 85A 100A MPPT Solar Charge Controller for solar home system, rv solar system,solar energy system MC

Produktbeschreibung

SRNE 60A 85A 100A MPPT Solar Charge Controller for solar home system, rv solar system,solar energy system MC



• PowerCatcher maximum power point tracking technology allows the controller to track the maximum power point of solar panels even in a complex environment. Compared with the traditional MPPT tracking technology, it boasts faster response speed and higher tracking efficiency.
• A built-in maximum power point tracking (MPPT) algorithm can significantly increase energy utilization efficiency of the photovoltaic system, which is about 15% to 20% higher than traditional PWM charging.
• It provides an active charging voltage regulation feature. At battery open circuit or lithium battery BMS overcharge protection, the controller battery terminal will output the rated charging voltage value.
• MPPT tracking efficiency is up to 99.9%.
• Due to an advanced digital power technology, the circuit energy conversion efficiency is as high as 98%.
• Available in multiple battery types and support charging procedures of various types of batteries such as lithium battery, colloidal battery, sealed battery, vented battery, lithium battery, etc.
• A current-limited charging mode is available. When the power of solar panel is too large and the charging current is higher than the rated valve, the controller automatically reduces the charging power
so that the solar panel can operate at the rated charging current.
• Support automatic identification of lead-acid battery voltage.
• External LCD screen or Bluetooth module can be connected for viewing of equipment operating data and status, and modification of controller parameters is supported.
• Support standard Modbus protocol to meet communication needs in different occasions.
• Built-in over-temperature protection mechanism ensures that when temperature exceeds the set value of the device, the charging current decreases linearly with the temperature, thereby reducing the temperature rise of controller and avoiding high temperature damage.
• Temperature compensation and automatic adjustment of charge and discharge parameters help to improve battery life.
• Solar panel short circuit protection, battery open circuit protection and TVS lightening protection etc.


Company information


Lieferfähigkeit

10000 Stück(e) Pro Tag

Verpackung und Versand

Vorlaufzeit:: 1 Tag

Hafen:: shenzhen

Verpackungsdetails:: 1pcs/one box total weight is 5.5KG/BOX

Produktspezifikationen

Maximalstrom:: 100A

Nennspannung.:: 48V

Markenname:: SRNE

Modell-Nr:: MC48100N25

Anwendung:: Solar System Controller

>=10 Stück(e)

US 400.00-450.00
